2002 2003 Nevada Base club 750 Front Rear Mudguard
| Position | Part Number | Description |
|---|---|---|
| 1 | 31434483 | #01 Front mudguard blank (#31434483) |
| 1 | 89000419 | #01 Front mudguard red baroque (#89000419) |
| 1 | 89000424 | #01 Front mudguard blue lord (#89000424) |
| 1 | 89000429 | #01 Front mudguard grey platinum (#89000429) |
| 1 | 89000434 | #01 Front mudguard grey iron (#89000434) |
| 1 | 89000439 | #01 Front mudguard beige sand (#89000439) |
| 2 | 31436684 | Stabilization Plate (#31436684) |
| 3 | 98350435 | #03 Screw (#98350435) |
| 4 | 31437074 | #04 Rear mudguard blank (#31437074) |
| 4 | 89000423 | #04 Rear mudguard red baroque (#89000423) |
| 4 | 89000428 | #04 Rear mudguard blue lord (#89000428) |
| 4 | 89000433 | #04 Rear mudguardgrey platinum (#89000433) |
| 4 | 89000438 | #04 Rear mudguard grey iron (#89000438) |
| 4 | 89000443 | #04 Rear mudguard beige sand (#89000443) |
| 5 | 31659783 | Eyelet (#31659783) |
| 6 | 13436561 | CABLE HOLDER (#13436561) |
| 7 | 92630206 | NUT (#92630206) |
| 8 | 31439565 | SCREW (#31439565) |
| 9 | 31920785 | #09 Sticker rear mudguard grey (#31920785) |
| 9 | 31920786 | #09 Sticker rear mudguard grey/wh (#31920786) |
| 9 | 31920787 | #09 Sticker rear mudguard red (#31920787) |
| 9 | 31920788 | #09 Sticker rear mudguard blue (#31920788) |
| 9 | 31920789 | #09 Sticker rear mudguard grey (#31920789) |
| 10 | 31439160 | #10 Rear mud'ard supp. (#31439160) |
| 11 | 98084320 | Screw (#98084320) |
| 12 | 95008306 | WASHER (#95008306) |
| 13 | 93110060 | RUBBER WASHER (#93110060) |
| 14 | 95100141 | WASHER (#95100141) |
| 15 | 92630707 | NUT (#92630707) |
| 16 | 98370621 | BOLT (#98370621) |
| 17 | 93231606 | RUBBER BUSHING (#93231606) |
