2002 California Special Sport al. PL 1100 Engine Transmission Cage
| Position | Part Number | Description |
|---|---|---|
| - | ||
| 1 | 3200260 | #01 Gearbox black (#3200260) |
| 2 | 90403547 | FORK SEAL- (#90403547) USE 90403449 |
| 3 | 92256218 | BEARING (#92256218) |
| 4 | 14213803 | PLATE (#14213803) |
| 5 | 98682316 | ALLEN BOLT (#98682316) |
| 6 | 14217901 | LOCK WASHER (#14217901) USE AP8152105 |
| 7 | 92218424 | Input and output bearing for 5 speed (#92218424) |
| 8 | 92234717 | BEARING, ROLLER (#92234717) |
| 9 | 95512081 | PIN (#95512081) |
| 10 | 14201110 | TRANS. COVER GASKET (#14201110) |
| 11 | 3200860 | #11 Case cover black (#3200860) |
| 12 | 90706140 | O RING (#90706140) |
| 13 | 92201417 | BEARING (#92201417) |
| 14 | 14237800 | SCREW (#14237800) |
| 15 | 92606512 | Low Nut (#92606512) |
| 16 | 98682325 | BOLT (#98682325) |
| 17 | 98680335 | SCREW (#98680335) |
| 18 | 12154200 | OIL LINE CRUSH WASHER (#12154200) |
| 19 | 19207220 | SWITCH, NEUTRAL (#19207220) |
| 20 | 3991560 | #20 Complete gearbox black (#3991560) |
| 21 | 30424660 | HOSE GUIDE (#30424660) |
| 22 | 93180220 | TIMING HOLE PLUG (#93180220) |
| 23 | 12022600 | PLUG (#12022600) |
| 24 | 90706203 | O RING (#90706203) |
| 25 | 95980214 | DRAIN PLUG (#95980214) |
| 26 | 1528930 | #26 Gasket 10x18x1,5 (#1528930) |
| 27 | 14204955 | PIPE (#14204955) |
| 28 | 823956080 | TUBE (#823956080) USE 00823956080 |
| 29 | 94321067 | SPRING (#94321067) |
| 30 | 28234700 | PIN (#28234700) |
| 31 | 90403548 | TRAN SEAL (#90403548) |
| 32 | 95980610 | PLUG (#95980610) |
| 33 | 93180245 | RUBBER PLUG (#93180245) |
| 34 | 31003766 | DRAIN PLUG (#31003766) |
| 35 | 98822325 | SCREW (#98822325) |
