2002 California Stone metal PL 1100 Dashboard
| Position | Part Number | Description |
|---|---|---|
| 1 | 02761500 | SPEEDO ASSY (#02761500) |
| 1 | 02762400 | SPEEDOMETER VEGLIA BRAND WHITE FACE (#02762400) |
| 1 | 03761565 | Blackface speedo KPH, Stone (#03761565) |
| 1 | 03762465 | 03 Stone Speedo, Black Face (#03762465) |
| 2 | 23768310 | ANGLE DRIVE (#23768310) |
| 3 | 02762800 | TRIP RESET KNOB (#02762800) |
| 4 | 01760400 | SPEEDO CABLE (#01760400) |
| 4 | 03760451 | Speedo Cable, Stone (#03760451) |
| 5 | 03762550 | SPEEDO DRIVE ASSY (#03762550) |
| 5 | 28762540 | SPEEDO DRIVE ASSY. (#28762540) |
| 6 | 01782500 | IGNITION SWITCH (#01782500) |
| 7 | 93400012 | Lamp Holder End (#93400012) |
| 8 | 93450119 | BULB 12V (#93450119) USE 163015 |
| 9 | 30735500 | IGNITION KEY BLANK (#30735500) |
| 10 | 03747265 | dash harness - ITI gauges (#03747265) |
| 11 | 02763000 | STUD A (#02763000) |
| 12 | 03764050 | INSTRUMENT SUPPORT PLATE BLACK (#03764050) |
| 13 | 02762301 | SPEEDO/TAC RUBBER GASKET (#02762301) |
| 14 | 97260415 | SECURITY BOLT A (#97260415) |
| 15 | 03762040 | CHROME LOWER CO (#03762040) |
| 15 | 03762050 | Speedometer Box (#03762050) |
| 16 | 03760051 | Dashboard complete (#03760051) |
| 17 | 03760052 | Dashboard complete (#03760052) |
| 18 | 01766040 | SOCKET PANEL BLACK (#01766040) |
| 19 | 02765500 | PANEL RUBBER (#02765500) |
| 20 | 91180721 | BUSHING (#91180721) |
| 21 | 98230640 | ALLEN BOLT (#98230640) |
| 22 | 95100124 | WASHER (#95100124) |
| 23 | 92660007 | NUT(#92660007) |
| 24 | 98692318 | ALLEN SCREW (#98692318) |
| 25 | 95008306 | WASHER (#95008306) |
| 26 | 91180411 | SPACER (#91180411) |
| 27 | 99220332 | SCREW (#99220332) |
| 28 | 95000205 | WASHER (#95000205) |
| 29 | 91180413 | SPACER A (#91180413) |
| 30 | 03758140 | WARNING LIGHT (#03758140) |
| 31 | 03758040 | WARNING LIGHT H A (#03758040) |
| 32 | 03766540 | COVER (#03766540) |
| 33 | 99210316 | SCREW (#99210316) |
| 34 | 93450140 | BULB (93450140) (#93450140) USE 164634 |
| 35 | 02768600 | LAMP HOLDER (#02768600) |
| 36 | 17762200 | RUBBER BOOT (#17762200) |
| 37 | 98230512 | SCREW (#98230512) USE 831153 |
| 38 | 95005305 | WASHER (#95005305) |
