2002 California Stone metal PL 1100 Front Lights
| Position | Part Number | Description |
|---|---|---|
| 1 | 03740540 | HEADLIGHT COMPLETE (#03740540) |
| 1 | 03740545 | LH HEADLIGHT SU D (#03740545) |
| 2 | 02746900 | H/L HARNESS (#02746900) |
| 3 | 01756100 | CONNECTOR 4 WAY (#01756100) |
| 4 | 91551033 | GROMMET A (#91551033) |
| 5 | 93450232 | CAL H/L BULB 60/55 (#93450232) USE 292723 |
| 6 | 01756220 | CONNECTOR 3 WAY (#01756220) |
| 7 | 93450119 | BULB 12V (#93450119) USE 163015 |
| 8 | 03496150 | H/L BRKT RH (#03496150) |
| 9 | 14439800 | SPACER (#14439800) |
| 10 | 95005308 | WASHER M8 (#95005308) |
| 11 | 03496250 | H/L BRKT LH (#03496250) |
| 12 | 98692318 | ALLEN SCREW (#98692318) |
| 13 | 98692325 | BOLT (#98692325) |
| 14 | 03750631 | TURN SIGNAL RH FRONT LH REAR (#03750631) |
| 15 | 03750630 | SIGNAL LAMP LH FRONT RH REAR (#03750630) |
| 16 | 93450127 | T/SIG. BULB - CLEAR (#93450127) |
| 17 | 31753765 | SIGNAL LENS AMBER (#31753765) USE AP8124111 |
| 18 | 98682314 | Screw (#98682314) |
| 19 | 14217901 | LOCK WASHER (#14217901) USE AP8152105 |
| 20 | 01743791 | Horn, Lowtone (#01743791) |
| 21 | 98682312 | Screw, 6x12mm (#98682312) |
| 22 | 14781670 | REFLECTOR (#14781670) |
| 23 | 03740430 | OPTICAL GROUP LENS & RIM ONLY. USA (#03740430) |
| 23 | 03740431 | OPTICAL FOR LH DRIVING (#03740431) use 29740500 |
| 24 | 03740437 | Cap rear black (#03740437) |
| 25 | 98064425 | BOLT (#98064425) |
| 26 | 95008306 | WASHER (#95008306) |
| 27 | 03744240 | HORN SUPPORT PL A (#03744240) |
