2002 V 11 Le Mans 1100 Cylinder Head And Valves
| Position | Part Number | Description |
|---|---|---|
| 1 | 01022130 | CYL. HEAD RH (#01022130) |
| 2 | 01022230 | CYL. HEAD LH (#01022230) |
| 3 | 13036801 | VALVE GUIDE (#13036801) |
| 4 | 14036860 | GUIDE (#14036860) |
| 5 | 37036105 | EXHAUST VALVE (#37036105) |
| 6 | 37036005 | INTAKE VALVE(#37036005) |
| 7 | 90353016 | VALVE GUIDE CLIP (#90353016) |
| 8 | 13037200 | WASHER (#13037200) |
| 9 | 14037300 | WASHER (#14037300) |
| 10 | 01038730 | WASHER (#01038730) |
| 11 | 37037405 | VALVESPRING OUTER (#37037405) |
| 12 | 37037605 | VALVE SPRING - INNER (#37037605) |
| 13 | 37038005 | RETAINER (#37038005) |
| 14 | 12038100 | HALF CONE (#12038100) |
| 15 | 12022600 | PLUG (#12022600) |
| 16 | 90706203 | O RING (#90706203) |
| 17 | ||
| 18 | 95129180 | WAVE WASHER (#95129180) |
| 19 | 96508040 | STUD (#96508040) |
| 20 | 30022060 | HEAD GASKET (#30022060) |
| 21 | 90706094 | O RING-VITON (#90706094) |
| 22 | 14034865 | SUPPORT (#14034865) |
| 23 | 92603010 | NUT A (#92603010) |
| 24 | 14018400 | WASHER (#14018400) |
| 25 | 14030201 | ROCKER ARM B (#14030201) |
| 26 | 14030401 | ROCKER ARM A (#14030401) |
| 27 | 91111511 | ROCK.ARM BSHG. (#91111511) |
| 28 | 17034050 | ADJ.SCREW (#17034050) |
| 29 | 10034100 | ROCKER ARM ADJUSTER NUT (#10034100) |
| 30 | 94322215 | SPRING-ROCKER (#94322215) |
| 31 | 90118152 | WASHER (#90118152) |
| 32 | 10032700 | WASHER (#10032700) |
| 33 | 12031800 | ROCKER SPINDLE (#12031800) |
| 34 | 98084316 | Screw (#98084316) |
| 35 | 95120065 | WASHER (#95120065) |
| 36 | 01023560 | VALVE COVER GREY (#01023560) |
| 37 | 01941030 | HEAD GUARD-GREY (#01941030) |
| 38 | 14023760 | V/C GASKET (#14023760) |
| 39 | 98682325 | BOLT (#98682325) |
| 40 | 95008206 | WASHER (#95008206) |
| 41 | 01037030 | LOWER CUP (#01037030) |
