2003 2004 California Aluminum Titanium 1100 Fuel Tank
| Position | Part Number | Description |
|---|---|---|
| 1 | 03100270 | FUEL TANK BLANK (#03100270) |
| 1 | 89000511 | FUEL TANK STEEL GREY (#89000511) |
| 1 | 89000512 | FUEL TANK 03 Titanium/FREY (#89000512) |
| 2 | 03917843 | RH GREY DECAL (#03917843) |
| 2 | 03917854 | Moto Guzzi L.H. decal (#03917854) |
| 3 | 03917943 | LH GREY DECAL (#03917943) |
| 3 | 03917954 | (#03917954) |
| 4 | 03106400 | MOULDING (#03106400) |
| 5 | 03103970 | GAS CAP USA (32103960) USE 887874 (#03103970) |
| 6 | 03101900 | GAS CAP FLANGE (#03101900) |
| 7 | 03102400 | FLANGE GASKET (#03102400) |
| 8 | 03102200 | GAS CAP SEAT (#03102200) |
| 9 | 03101600 | GAS CAP GASKET (#03101600) |
| 10 | 03101720 | RESTRICTOR 38MM (#03101720) |
| 11 | 03103200 | SCREW A (#03103200) |
| 12 | 98350430 | Hex Socket Screw (#98350430) |
| 13 | 95100239 | WASHER (#95100239) |
| 14 | 31103565 | SPACER (#31103565) |
| 15 | 91551131 | GROMMET (#91551131) |
| 16 | 92660801 | CAGE NUT (#92660801) |
| 17 | 30944300 | WARNING DECAL (#30944300) |
| 18 | 03921566 | Sticker LH gold (#03921566) |
| 18 | 03921568 | Sticker LH silver (#03921568) |
| 19 | 03736870 | LOCK KIT (#03736870) |
| 20 | 30735500 | IGNITION KEY BLANK (#30735500) |
| 21 | 03917570 | DECAL SILVER EAGLE RED/WHITE/GREEN ON BOTTOM.1921 (#03917570) |
| 22 | 03472460 | RH Plate (#03472460) USE 034724605 |
| 23 | 03472960 | LH Front Protect, Black (#03472960) |
| 24 | 98370619 | BOLT (#98370619) |
| 25 | 03462801 | Washer (#03462801) |
| 26 | 91180600 | SPACER (#91180600) |
| 27 | 91551081 | GROMMET (#91551081) |
| 28 | 00823931055 | GASKET (#00823931055) |
| 29 | 03103500 | SPACER (#03103500) |
| 30 | 03921565 | Sticker RH gold (#03921565) |
| 30 | 03921567 | Sticker RH silver (#03921567) |
| 31 | 03995730 | DECAL UNLEADED FUEL ONLY (#03995730) |
| 32 | 03104370 | #40 Tank cap ring and spring kit (#03104370) |
