2003 2004 California Aluminum Titanium 1100 Saddle Central Bod
| Position | Part Number | Description |
|---|---|---|
| 1 | 03460560 | FRONT SEAT (#03460560) |
| 2 | 03464060 | REAR SEAT (#03464060) |
| 3 | 92630106 | NUT USE 92630707 (#92630106) |
| 4 | 03467330 | PANEL RH PRIMER A (#03467330) |
| 4 | 03467366 | Cover RH (Steel) (#03467366) |
| 4 | 03467367 | Cover RH (Titanium) (#03467367) |
| 5 | 03558165 | RH SHOCK COVER (#03558165) |
| 5 | 03558167 | RH SHOCK COVER(#03558167) |
| 6 | 03466930 | PANEL LH PRIMER A (#03466930) |
| 6 | 03466966 | Cover LH (#03466966) |
| 6 | 03466967 | Cover LH (#03466967) |
| 7 | 03558265 | SHOCK COVER (#03558265) |
| 7 | 03558267 | LH SHOCK CVR, TITANIUM (#03558267) |
| 8 | 95100141 | WASHER (#95100141) |
| 9 | 00823931082 | 12235301 |
| 10 | 98223830 | UPPER SCREW (#98223830) |
| 11 | 03459330 | SPACER-UPPER (#03459330) |
| 12 | 91551165 | GROMMET (#91551165) |
| 13 | 98223625 | Lower Screw, 6x25mm (#98223625) |
| 14 | 03459331 | SPACER A (#03459331) |
| 15 | 91551010 | GROMMET (#91551010) |
| 16 | 03476265 | RH SIDE COVER, BARE (#03476265) |
| 16 | 03476268 | RH SIDE COVER, TITANIUM (#03476268) |
| 17 | ||
| 18 | 03922066 | Sticker CALIFORNIA TITANIUM (#03922066) |
| 19 | 39922200 | PLATE (#39922200) |
| 20 | 03476365 | LH Sidecover, Bare (#03476365) |
| 20 | 03476368 | LH Sidecover, Titanium (#03476368) |
| 21 | 03922067 | Sticker CALIFORNIA TITANIUM (#03922067) |
| 22 | 03476269 | RH Side Cover-Aluminum (#03476269) |
| 23 | 03478265 | Front Plate LH (#03478265) |
| 24 | 03478331 | PLATE LH A (#03478331) |
| 25 | 98682318 | Screw (#98682318) |
| 26 | 95008206 | WASHER (#95008206) |
| 27 | 92660601 | CAGE NUT (#92660601) |
| 28 | 03478330 | PLATE RH A (#03478330) |
| 29 | 02573900 | GROMMET (#02573900) |
| 30 | 03478165 | Front Plate RH (#03478165) |
| 31 | 98350315 | Screw (#98350315) |
| 32 | 03945455 | DECAL-FUSEBOX (#03945455) |
| 33 | 03476369 | LH Side Cover-Aluminum (#03476369) |
| 34 | 03922165 | Sticker line RH gold (#03922165) |
| 35 | 03922166 | Sticker line LH gold (#03922166) |
| 36 | 03922167 | Sticker line RH silver (#03922167) |
| 37 | 03922168 | Sticker line LH silver (#03922168) |
