2003 2004 California Stone touring pl cat 1100 Fuel Tank
| Position | Part Number | Description |
|---|---|---|
| 1 | 03100270 | FUEL TANK BLANK (#03100270) |
| 1 | 89000515 | Fuel tank red (#89000515) |
| 1 | 89000516 | FUEL-TANK BLACK (#89000516) |
| 1 | 89000517 | Fuel tank chrome grey (#89000517) |
| 2 | 03917853 | Decal RH (#03917853) |
| 2 | 03917854 | Moto Guzzi L.H. decal (#03917854) |
| 3 | 03917953 | DECAL LH (#03917953) |
| 3 | 03917954 | (#03917954) |
| 4 | 03106400 | MOULDING (#03106400) |
| 5 | 03103970 | GAS CAP USA (32103960) USE 887874 (#03103970) |
| 6 | 03101900 | GAS CAP FLANGE (#03101900) |
| 7 | 03102400 | FLANGE GASKET (#03102400) |
| 8 | 03102200 | GAS CAP SEAT (#03102200) |
| 9 | 03101600 | GAS CAP GASKET (#03101600) |
| 10 | 03101720 | RESTRICTOR 38MM (#03101720) |
| 11 | 03103200 | SCREW A (#03103200) |
| 12 | 98350430 | Hex Socket Screw (#98350430) |
| 13 | 95100239 | WASHER (#95100239) |
| 14 | 31103565 | SPACER (#31103565) |
| 15 | 91551131 | GROMMET (#91551131) |
| 16 | 92660801 | CAGE NUT (#92660801) |
| 17 | 03917553 | Transfer dark tan (#03917553) |
| 17 | 03917554 | Transfer black (#03917554) |
| 18 | 03917653 | Sticker line dark silver (#03917653) |
| 18 | 03917654 | TANK STRIPE (#03917654) |
| 19 | 03736870 | LOCK KIT (#03736870) |
| 20 | 30735500 | IGNITION KEY BLANK (#30735500) |
| 21 | 30944300 | WARNING DECAL (#30944300) |
| 22 | 03103500 | SPACER (#03103500) |
| 23 | 30472460 | SHROUD RH (#30472460) |
| 24 | 30472960 | SHROUD LH A (#30472960) |
| 25 | 95005320 | WASHER (#95005320) |
| 26 | 98350312 | CLUTCH MOUNT SCREW (#98350312) |
| 27 | 03104370 | #40 Tank cap ring and spring kit (#03104370) |
