2003 2004 California Stone touring pl cat 1100 Side Cases
| Position | Part Number | Description |
|---|---|---|
| 1 | 03484370 | Kit bag inserts unpainted (#03484370) |
| 1 | 03484373 | Inserts kit black (#03484373) |
| 1 | 03484374 | Kit bag insert Platinum Gray (#03484374) |
| 2 | 03482570 | RH Bag 40 L for painted insert (#03482570) |
| 3 | 03485770 | LH Bag 40 L for painted insert (#03485770) |
| 4 | 03482070 | Hepco Becker Logo, RH (#03482070) |
| 5 | 03485075 | RH Bag bracket, Stone Touring (#03485075) |
| 6 | 03486575 | LH Bag bracket, Stone Touring (#03486575) |
| 7 | 98680475 | Screw, 8x75mm (#98680475) |
| 8 | 95129131 | Washer (#95129131) |
| 9 | 29482400 | DECAL 10KG MAX (#29482400) |
| 10 | 98350318 | SCREW (#98350318) |
| 11 | 92640106 | #10 Selflocking nut (#92640106) |
| 12 | 03484000 | BAG CLAMP KIT (#03484000) |
| 13 | 03484001 | SADDLEBAG LOCK (#03484001) |
| 14 | 00979726 | BAG JOINT PLATE (#00979726) |
| 15 | 98080485 | screw M8X85 (#98080485) |
| 16 | 03484470 | RH bags insert unpainted (#03484470) |
| 16 | 03484473 | RH bag insert black shadow (#03484473) |
| 16 | 03484474 | RH bag insert platinum gray (#03484474) |
| 17 | 03484570 | LH bags insert unpainted (#03484570) |
| 17 | 03484573 | LH bag insert black shadow (#03484573) |
| 17 | 03484574 | LH bag insert platinum gray (#03484574) |
| 18 | 03482071 | Hepco Becker Logo, LH (#03482071) |
| 19 | 95005308 | WASHER M8 (#95005308) |
| 20 | 92640508 | Nut (#92640508) |
| 21 | 98680440 | Screw (#98680440) |
