2003 2004 V 11 1100 Exhaust Unit
| Position | Part Number | Description |
|---|---|---|
| 1 | 01120990 | EXHAUST PIPE RH (#01120990) |
| 2 | 01120991 | EXHAUST PIPE LH (#01120991) |
| 3 | 90718370 | EXHAUST GASKET (#90718370) |
| 4 | 98370835 | ALLEN BOLT (#98370835) |
| 5 | 01121030 | EXHAUST PIPE FLANGE (#01121030) |
| 6 | 14615901 | WASHER (#14615901) |
| 7 | 92787008 | NUT (#92787008) USE 860651 |
| 8 | 95005308 | WASHER M8 (#95005308) |
| 9 | 98110007 | PLUG (#98110007) |
| 10 | 30109330 | COPPER WASHER (#30109330) |
| 11 | 01126930 | MUFFLER CLAMP (#01126930) |
| 12 | 01123931 | EXH COLLECTOR (#01123931) |
| 12 | 01123990 | EXH COLLECTOR (#01123990) |
| 13 | 01123830 | EXHAUST COLLECTOR BRACKET (#01123830) |
| 14 | 98084412 | Screw (#98084412) |
| 15 | 93233030 | VIBRATION DAMPER (#93233030) |
| 16 | 30126700 | SPACER-TEFLON A (#30126700) |
| 17 | 30126701 | SPACER-TEFLON A (#30126701) |
| 18 | 95100239 | WASHER (#95100239) |
| 19 | 98084430 | Screw, 8mmx30mm (#98084430) |
| 20 | 14103400 | TANK BUSHING (#14103400) |
| 21 | 01123430 | EXHAUST CLAMP (#01123430) |
| 22 | 98084422 | Screw, 8mmx22mm (#98084422) |
| 23 | 95005309 | WASHER, 8.25x30x2 (#95005309) |
| 24 | 92650108 | Nut, 8mmx1.25 (#92650108) |
| 25 | 01123061 | RH MUFFLER (#01123061) |
| 25 | 01123090 | RH MUFFLER BLACK (#01123090) |
| 26 | 01122961 | SILENCER LH (#01122961) |
| 26 | 01122990 | LH MUFFLER BLACK (#01122990) |
| 27 | 95187008 | LOCK PLATE (#95187008) USE 1461 5901 |
| 28 | 91180819 | Spacer, 8.5x12x16 (#91180819) |
| 29 | 92650138 | Nut (#92650138) |
| 30 | 01122690 | Exhaust pipe (#01122690) |
| 31 | 91113230 | gasket (#91113230) |
| 32 | 32727010 | SENSOR-LAMDA (#32727010) |
| 33 | 400086800910 | MUFFLER GUARD KIT (#400086800910) |
