2003 2005 California EV PL Cat. 1100 Double Plate Clutch 2nd Series
| Position | Part Number | Description |
|---|---|---|
| 1 | 13084100 | CLUTCH SPRING (#13084100) |
| 2 | 12082901 | PRESSURE PLATE (#12082901) |
| 3 | 05084430 | CLUTCH PLATE DEEP SPLINE (#05084430) |
| 4 | 12082300 | CLUTCH INTERMEDIATE PLATE (#12082300) |
| 5 | 12082800 | CUP OR NUT (#12082800) |
| 6 | 14085700 | CLUTCH PUSH ROD 5 SPEED, 9 11/16 (#14085700) |
| 7 | 14085900 | CLUTCH PUSH ROD SEAL (TAKES 2) (#14085900) |
| 8 | 14086000 | INNER CLUTCH BODY (#14086000) |
| 9 | 12087001 | THROWOUT BEARING 5 SPEED (12087001) |
| 10 | 14086100 | OUTER CLUTCH BODY (#14086100) |
| 11 | 90706170 | O RING (#90706170) |
| 12 | ||
| 13 | 94321105 | SPRING (#94321105) |
| 14 | 14090400 | SCREW (#14090400) |
| 15 | 92606508 | Nut (#92606508) |
| 16 | 95780271 | PIN (#95780271) |
| 17 | 95500222 | SPLIT PIN (#95500222) |
