2003 2005 California EV PL Cat. 1100 Engine Heads

Position Part Number Description
-
- 14030201 ROCKER ARM B (#14030201)
- 14030401 ROCKER ARM A (#14030401)
- 37037405 VALVESPRING OUTER (#37037405)
- 37037605 VALVE SPRING - INNER (#37037605)
- 37038005 RETAINER (#37038005)
1 3022130 #01 RH head assy w/h valve grey (#3022130)
2 30022260 CYL HEAD LH C (#30022260)
3 13036801 VALVE GUIDE (#13036801)
4 14036860 GUIDE (#14036860)
5 3036100 #05 Exhaust valve (#3036100)
6 3036000 #06 Intake valve (#3036000)
7 90353016 VALVE GUIDE CLIP (#90353016)
8 13037200 WASHER (#13037200)
9 14037300 WASHER (#14037300)
10
11 13037400 OUTER SPRING (#13037400)
12 13037600 INNER SPRING (#13037600)
13 14038000 UPPER COLLAR (#14038000)
14 12038100 HALF CONE (#12038100)
15 12022600 PLUG (#12022600)
16 90706203 O RING (#90706203)
17
18 95129180 WAVE WASHER (#95129180)
19 96508040 STUD (#96508040)
20 30022060 HEAD GASKET (#30022060)
21 90706094 O RING-VITON (#90706094)
22 14034865 SUPPORT (#14034865)
23 92603010 NUT A (#92603010)
24 14018400 WASHER (#14018400)
25 3030230 #25 RH rocker arm assy (#3030230)
26
27 91111511 ROCK.ARM BSHG. (#91111511)
28
29 98692325 BOLT (#98692325)
30 94322215 SPRING-ROCKER (#94322215)
31 90118152 WASHER (#90118152)
32 10032700 WASHER (#10032700)
33 12031800 ROCKER SPINDLE (#12031800)
34 98084316 Screw (#98084316)
35 95120065 WASHER (#95120065)
36 3023530 #36 RH/LH head cover polished (#3023530)
37
38 14023760 V/C GASKET (#14023760)
39
40 10034100 ROCKER ARM ADJUSTER NUT (#10034100)
