2003 2005 California EV PL Cat. 1100 F Fork R Shock Absorber
| Position | Part Number | Description |
|---|---|---|
| 1 | 03490270 | Front fork (#03490270) |
| 2 | 30513401 | NUT (#30513401) |
| 3 | 30516500 | WASHER (#30516500) |
| 4 | 14516700 | SHIM (#14516700) |
| 5 | 14517000 | RING DUST SEAL (#14517000) |
| 6 | 92249225 | TAPERED ROLLER BRNG (#92249225) |
| 7 | 03531800 | SHOCK MOUNT PLATE (#03531800) |
| 8 | 03531000 | BRACKET A (#03531000) |
| 9 | 03530270 | STEERING DAMPER (#03530270) |
| 10 | 98084325 | Hex screw (#98084325) |
| 11 | 95008306 | WASHER (#95008306) |
| 12 | 92630707 | NUT (#92630707) |
| 13 | 98370619 | BOLT (#98370619) |
| 14 | 95005306 | WASHER (#95005306) |
| 15 | 03550211 | V11 TOURING SHOCK (#03550211) |
| 15 | 03550212 | Rear shock absorber SACHS (#03550212) |
| 16 | 03541850 | PIVOT PIN (#03541850) |
| 17 | 95129240 | WASHER A (#95129240) |
| 18 | 95005330 | Washer (#95005330) |
| 19 | AP8152278 | #12 Screw w/ flange M6x16* (#AP8152278 ) |
| 20 | 95100141 | WASHER (#95100141) |
| 21 | 01517700 | BADGE (#01517700) |
| 22 | AP8152277 | Screw w/flange (#AP8152277) |
