2003 2005 California EV PL Cat. 1100 Frame Electrical System II
| Position | Part Number | Description |
|---|---|---|
| - | 1722700 | #20 Gasket 0,3mm (#1722700) |
| - | 1722701 | #17 Gasket 0,4mm (#1722701) |
| - | 1722702 | #20 Gasket 0,6mm (#1722702) |
| - | 1722703 | #20 Gasket 0,8mm (#1722703) |
| - | 1722704 | #17 Gasket 1mm (#1722704) |
| - | 1722705 | #20 Gasket 1,5mm (#1722705) |
| - | 3729555 | #02 CDI unit assy (#3729555) |
| - | 28742558 | Fuse, 5A (#28742558) |
| 1 | 3725875 | #01 Injection wiring (#3725875) |
| 2 | 3729565 | #02 CDI unit assy USA (#3729565) |
| 3 | 1732530 | #03 Relay Siemens A302B1005 (#1732530) |
| 4 | 28742559 | FUSE 10A (#28742559) |
| 5 | 3729230 | #05 Plate (#3729230) |
| 6 | 93221330 | RUBBER MOUNT (#93221330) |
| 7 | 98084110 | Hex screw M4X10 (#98084110) |
| 8 | 95008304 | Washer (#95008304) |
| 9 | 98682310 | Screw (#98682310) |
| 10 | 95100141 | WASHER (#95100141) |
| 11 | 92660601 | CAGE NUT (#92660601) |
| 12 | 3718350 | #12 HT wire (#3718350) |
| 13 | 14717600 | SPARK PLUG RUBBER BOOT (#14717600) |
| 14 | 3717450 | #20 Sparkplug cap (#3717450) |
| 15 | 30717061 | SPARK PLUG BPR6ES (#30717061) |
| 16 | 1721600 | #16 Phase/revolution sensor (#1721600) |
| 17 | 98682212 | Hex Socket Screw (#98682212) |
| 18 | 30729330 | AIR TEMP SENSOR (#30729330) |
| 19 | 90706141 | O RING (#90706141) USE 847180 |
| 20 | 29722760 | SENSOR GASKET (#29722760) |
| 21 | 30716500 | IGNITION COIL (#30716500) |
| 22 | 3716770 | #22 Coil holder (#3716770) |
| 23 | 95008205 | Washer 5.3mm (#95008205) |
| 24 | 30759600 | CABLE BOOT A (#30759600) |
| 25 | 98682125 | Screw (#98682125) |
| 26 | 92606206 | Nut (#92606206) |
| 27 | 95021204 | Washer (#95021204) |
| 28 | 93222023 | Silent - Block (#93222023) |
| 29 | 30728230 | BRACKET A (#30728230) |
| 30 | 98680110 | Screw (#98680110) |
| 31 | 30732200 | FUSE HOLDER (#30732200) |
| 32 | 30732400 | RELAY HOLDER (#30732400) |
| 33 | 92606003 | Nut M3 (#92606003) |
| 34 | 29729461 | OIL TEMP SENSOR (#29729461) |
| 35 | 3163330 | #35 Sensor support (#3163330) |
| 36 | 95008210 | Washer (#95008210) |
| 37 | 92630204 | Nut (#92630204) |
| 38 | 3738500 | #38 Fuel pump wiring (#3738500) |
| 39 | 95008306 | WASHER (#95008306) |
| 40 | ||
| 41 | 95120033 | Washer (#95120033) |
