2003 2005 California EV PL Cat. 1100 Frame Front Fork
| Position | Part Number | Description |
|---|---|---|
| - | 3530536 | #48 Calibration blade 15 mm (#3530536) |
| - | 3530537 | #48 Calibration blade 17 mm (#3530537) |
| 1 | 98622430 | SCREW (#98622430) |
| 2 | 3500660 | #02 Ubolt (#3500660) |
| 3 | 98052560 | BOLT (#98052560) |
| 4 | 3500260 | #04 Lower Ubolt (#3500260) |
| 5 | 27530505 | WASHER (#27530505) USE AP8123511 |
| 6 | ||
| 7 | 3493100 | #07 Fork upper plate (#3493100) |
| 8 | 3498100 | #08 Ring nut (#3498100) |
| 9 | 91181039 | Spacer (#91181039) |
| 10 | 92630110 | NUT (#92630110) |
| 11 | 3494000 | #11 Stem base (#3494000) |
| 12 | 3530504 | #12 Screw (#3530504) |
| 13 | 3530505 | #13 RH adjustment knob rebound (#3530505) |
| 14 | 3530506 | #04 Screw with OR (#3530506) |
| 15 | 3530507 | #15 Plug cpl. (#3530507) |
| 16 | 3530508 | #46 Cup (#3530508) |
| 17 | ||
| 18 | 3526600 | #18 Spring (#3526600) |
| 19 | 3525400 | #19 Sleeve (#3525400) |
| 20 | 3530510 | #20 Lower bush (#3530510) |
| 21 | 3530511 | #03 Ring (#3530511) |
| 22 | 3530512 | #22 RH hub (#3530512) |
| 23 | 3530513 | #23 Return nut (#3530513) |
| 24 | ||
| 25 | 3530515 | #25 Return spring (#3530515) |
| 26 | 3530516 | #26 RH piston rebound (#3530516) |
| 27 | 3530517 | #27 RH piston segmentrebound (#3530517) |
| 28 | 3530518 | #28 RH needle rebound (#3530518) |
| 29 | ||
| 30 | 3530520 | #30 Nut (#3530520) |
| 31 | 3530521 | #34 Stroke limit stop (#3530521) |
| 32 | 3530522 | #29 O-ring (#3530522) |
| 33 | ||
| 34 | 3530524 | #22 Dust cover (#3530524) |
| 35 | 3530525 | #23 Stop ring (#3530525) |
| 36 | 3530526 | FORK SEAL (#3530526) |
| 37 | 3530527 | #25 Cup (#3530527) |
| 38 | 3530528 | #26 Upper bush (#3530528) |
| 39 | 3522501001 | #30 RH sleeve (#3522501001) |
| 40 | 98620340 | SCREW (#98620340) |
| 41 | 3530529 | #02 Washer (#3530529) |
| 42 | 3530530 | #01 Screw M10x30 (#3530530) |
| 43 | 3522601001 | #28 LH sleeve (#3522601001) |
| 44 | 3530531 | #44 LH adjustment knob comp. (#3530531) |
| 45 | 3530532 | #45 LH hub (#3530532) |
| 46 | ||
| 47 | 3530534 | #47 Cup (#3530534) |
| 48 | 3530535 | #48 Calibration blade 12 mm (#3530535) |
| 49 | 3530538 | LH needle compression (#3530538) USE 03530538 |
| 50 | 3530539 | #50 LH piston compression (#3530539) |
| 51 | 3530540 | #51 Nut (#3530540) |
| 52 | ||
| 53 | ||
| 54 | 95005306 | WASHER (#95005306) |
| 55 | 3530541 | #13 Oring (#3530541) |
| 56 | 23943410 | CHROME PLUG (#23943410) |
| 57 | 98370619 | BOLT (#98370619) |
| 58 |
