2003 2005 California EV PL Cat. 1100 Frame Saddle Central Bod
| Position | Part Number | Description |
|---|---|---|
| - | 3476206 | #03 RH side cover blank (#3476206) |
| - | ||
| - | ||
| - | ||
| - | ||
| - | 3476306 | #08 LH side cover blank (#3476306) |
| - | ||
| - | ||
| - | ||
| - | ||
| - | ||
| - | ||
| 1 | ||
| 2 | ||
| 3 | ||
| 4 | ||
| 5 | 98370616 | BOLT (#98370616) |
| 6 | 66478610 | WASHER (#66478610) |
| 7 | 92660601 | CAGE NUT (#92660601) |
| 8 | ||
| 9 | ||
| 10 | 3945455 | Sticker schema fusibili (#3945455) USE 03945455 |
| 11 | ||
| 12 | ||
| 13 | 98370645 | Screw (#98370645) |
| 14 | 3462801 | #25 Washer (#3462801) |
| 15 | 91551105 | GROMMET (#91551105) |
| 16 | ||
| 17 | 28576591 | CLIP (#28576591) |
| 18 | 98370625 | ALLEN SCREW (#98370625) USE STAB6X25 |
| 19 | ||
| 20 | 91551106 | GROMMET (#91551106) |
| 21 | 91120806 | SPACER (#91120806) |
| 22 | 823931055 | MOULDING (#823931055) |
| 23 | ||
| 24 | ||
| 25 | ||
| 26 | 95100141 | WASHER (#95100141) |
| 27 | 92630106 | NUT USE 92630707 (#92630106) |
