2003 2005 California EV PL Cat. 1100 Rear Lights
| Position | Part Number | Description |
|---|---|---|
| 1 | 03475813 | T/L SHELL VINTAGE RED (#03475813) |
| 1 | 03475814 | Headlight Holder, Blue Slate (#03475814) |
| 1 | 03475815 | Headlight holder grey m. (#03475815) |
| 1 | 03475816 | Headlight Holder, Grey Luce (#03475816) |
| 1 | 03475830 | T/LAMP SHELL BA A (#03475830) |
| 1 | 03475860 | TAIL LAMP BRACKET BLACK (#03475860) |
| 2 | 03475931 | Support Rubber (#03475931) |
| 3 | ||
| 4 | 98682320 | Screw (#98682320) |
| 5 | 95001206 | WASHER (#95001206) |
| 6 | 92660600 | CAGE NUT (#92660600) |
| 7 | ||
| 8 | 93450127 | T/SIG. BULB - CLEAR (#93450127) |
| 9 | 31753765 | SIGNAL LENS AMBER (#31753765) USE AP8124111 |
| 10 | 03740930 | TAIL LAMP EURO (#03740930) |
| 11 | 98680150 | SCREW (#98680150) |
| 12 | 93450224 | BULB T.L. (#93450224) |
| 13 | 03741230 | BUSHING (#03741230) |
| 14 | 93231604 | WELL NUT (#93231604) |
| 15 | 03742030 | BUSHING (#03742030) |
| 16 | 03758471 | Rear Taillight Assembly, Black (#03758471) |
| 16 | 03758472 | Rear Taillight Assembly, Red (#03758472) |
| 16 | 03758473 | Rear Taillight Assembly, Blue (#03758473) |
| 16 | 03758474 | Rear Taillight Assy, Grey Magn (#03758474) |
| 16 | 03758475 | Rear Taillight Assy, Grey Luce (#03758475) |
| 17 | 95008205 | Washer 5.3mm (#95008205) |
| 18 | 01474630 | TAG HOLDER (#01474630) |
| 19 | 03474530 | LAMP MOUNT EUR A (#03474530) |
| 20 | 98370515 | ALLEN SCREW (#98370515) |
| 21 | 93110060 | RUBBER WASHER (#93110060) |
| 22 | 92650035 | Nut (#92650035) |
| 23 | 03438830 | CAP (#03438830) |
| 24 | 03438831 | CAP (#03438831) |
| 25 | 03475330 | LAMP MOUNT (#03475330) |
| 26 | 31745865 | REFLECTOR RED A (#31745865) |
| 27 | 92650034 | Nut (#92650034) |
| 28 | 03753170 | Wire (#03753170) |
| 29 | 14781570 | REFLECTOR (#14781570) |
| 30 | 14781870 | BRACKET (#14781870) |
