| Position |
Part Number |
Description |
| 1 |
32576610
|
RH Bumper - Breva (#32576610) |
| 1 |
977325
|
RH protection grey (#977325) |
| 2 |
32573210Y05
|
PRESA ARIA DX GRIGIO LUCE BREVA 750 (#32573210Y05) |
| 2 |
32576210
|
RH Air Intake, Blank - Breva (#32576210) |
| 2 |
32576211
|
RH Air Vent Dark Grey - Breva (#32576211) |
| 2 |
32576212
|
RH lat.fairing, grey cr. (#32576212) |
| 2 |
32576213
|
RH Air Intake, Silver - Breva (#32576213) |
| 2 |
32576214
|
RH lat.fairing, grey pl. (#32576214) |
| 2 |
32576215
|
PRESA ARIA DX TECHNOGREY (#32576215) |
| 2 |
32576281
|
PRESA ARIA DX BIANCO (#32576281) |
| 2 |
977313
|
RH fairing - red (#977313) |
| 2 |
977315
|
RH fairing black (#977315) |
| 2 |
977459
|
RH lateral fairing, sky blue (#977459) |
| 2 |
977539
|
RH SIDE PANEL BREVA 750 - WHITE (#977539) |
| 3 |
AP8102375
|
Clip (#AP8102375) |
| 4 |
32573310Y05
|
PRESA ARIA SX GRIGIO LUCE BREVA 750 (#32573310Y05) |
| 4 |
32576310
|
LH Air Vent Black - Breva (#32576310) |
| 4 |
32576311
|
LH Air Vent Dark Grey - Breva (#32576311) |
| 4 |
32576312
|
LH lat.fairing, grey cr. (#32576312) |
| 4 |
32576313
|
LH Air Vent Silver - Breva (#32576313) |
| 4 |
32576314
|
LH lat.fairing, grey pl. (#32576314) |
| 4 |
32576315
|
LH lat.fairing technogrey (#32576315) |
| 4 |
32576381
|
PRESA ARIA SX BIANCO (#32576381) |
| 4 |
977314
|
LH lat.fairing, red (#977314) |
| 4 |
977316
|
LH lat.fairing, black (#977316) |
| 4 |
977460
|
LH lateral fairing, sky blue (#977460) |
| 4 |
977540
|
LH SIDE PANEL BREVA 750 - WHITE (#977540) |
| 5 |
32576710
|
LH Bumper - Breva (#32576710) |
| 5 |
977326
|
LH protection grey (#977326) |
| 6 |
AP8150413
|
Self-Tap Screw (#AP8150413) |
| 7 |
32476410
|
Water Cooler Grille - Breva (#32476410) |
| 8 |
AP8152302
|
SCREW W/ FLANGE (#AP8152302) USE 2B014101 |
| 8 |
AP8152339
|
SCREW W/FLANGE (#AP8152339) |
