2004 2007 Mgs 01 Corsa 1200 Air Box
| Position | Part Number | Description |
|---|---|---|
| 1 | 02114050 | Air box (#02114050) |
| 2 | AP8104211 | AIR FILTER (#AP8104211) |
| 3 | 02113750 | Air filter cover (#02113750) |
| 4 | 92640406 | Nut M6 (#92640406) |
| 5 | 02113850 | Rod (#02113850) |
| 6 | 01114850 | SLEEVE A (#01114850) |
| 7 | 02113350 | Box cover (#02113350) |
| 8 | AP8152272 | Screw w/flange (#AP8152272) |
| 9 | AP8152273 | Screw w/flange (#AP8152273) |
| 10 | 92630703 | Nut (#92630703) |
| 11 | 91551086 | GROMMET (#91551086) |
| 12 | 91110508 | Spacer (#91110508) |
| 13 | 30729330 | AIR TEMP SENSOR (#30729330) |
| 14 | 98680110 | Screw (#98680110) |
| 15 | AP8120772 | Oil breather pipe (#AP8120772) |
| 16 | 00823923140 | THERMAL SHEATH (#00823923140) |
| 17 | 92640506 | Nut, 6mmx1.0 (#92640506) |
| 18 | 95100118 | WASHER (#95100118) |
