2004 2007 Mgs 01 Corsa 1200 Electrical System II
| Position | Part Number | Description |
|---|---|---|
| 1 | 02747150 | Main wiring harness (#02747150) |
| 2 | 02704550 | Battery 12V-11Ah (#02704550) |
| 3 | 02418250 | Plate (#02418250) |
| 4 | 91551086 | GROMMET (#91551086) |
| 5 | AP8152278 | #12 Screw w/ flange M6x16* (#AP8152278 ) |
| 6 | 28576591 | CLIP (#28576591) |
| 7 | 02418650 | Battery plate (#02418650) |
| 8 | 30716500 | IGNITION COIL (#30716500) |
| 9 | 98622125 | ALLEN BOLT A (#98622125) |
| 10 | AP8220546 | Relay Rubber (#AP8220546) |
| 11 | 92630204 | Nut (#92630204) |
| 12 | 02729550 | CDI unit assy (#02729550) |
| 13 | 93221315 | MOUNT (#93221315) |
| 14 | 98084110 | Hex screw M4X10 (#98084110) |
| 15 | 28742560 | FUSE 15A (#28742560) use 290860 |
| 15 | 28742562 | FUSE 30A (#28742562) |
| 15 | AP8127346 | FUSE 3 A (#AP8127346) |
| 16 | AP8124869 | INJECTION RELAY (#AP8124869) USE #895481 |
| 17 | 14609650 | TIE WRAP (#14609650) |
| 18 | 90706178 | O RING (#90706178) |
