2004 2007 Mgs 01 Corsa 1200 Fuel Tank
| Position | Part Number | Description |
|---|---|---|
| 1 | 02100250 | Fuel tank (#02100250) |
| 2 | AP8144421 | Fuel tank gasket (#AP8144421) |
| 3 | AP8134706 | Fuel pump flange (#AP8134706) |
| 4 | AP8134712 | Fuel pump support (#AP8134712) |
| 5 | AP8152306 | Self-Locking Nut (#AP8152306) |
| 6 | 02103950 | Fuel filler cap (#02103950) |
| 7 | 02104650 | Fuel filler cap gasket (#02104650) |
| 8 | 02100750 | Plate (#02100750) |
| 9 | AP8152280 | Screw (#AP8152280) |
| 10 | 28576591 | CLIP (#28576591) |
| 11 | 02571950 | RH clamp (#02571950) |
| 12 | 02571951 | LH clamp (#02571951) |
| 13 | 98350210 | Screw (#98350210) |
| 14 | 95008205 | Washer 5.3mm (#95008205) |
| 15 | AP8121075 | T. Bushing (#AP8121075) |
