2005 2008 Griso V ie 1100 Cylinder Head And Valves I
| Position | Part Number | Description |
|---|---|---|
| 1 | 05022130 | RH head assy w/h valve (#05022130) |
| 1 | 05022132 | RH HEAD ASSY W/H VALVE GREY (#05022132) |
| 2 | 05022230 | LH head assy with valve (#05022230) |
| 2 | 05022232 | TESTA SX VERN TWIN SPARK SINT (#05022232) |
| 3 | 13036801 | VALVE GUIDE (#13036801) |
| 4 | 14036860 | GUIDE (#14036860) |
| 5 | 05036131 | Exhaust valve (#05036131) |
| 6 | 05036030 | Intake Valve (#05036030) |
| 7 | 90353016 | VALVE GUIDE CLIP (#90353016) |
| 8 | 13037200 | WASHER (#13037200) |
| 9 | 14037300 | WASHER (#14037300) |
| 10 | 01038730 | WASHER (#01038730) |
| 11 | 37037405 | VALVESPRING OUTER (#37037405) |
| 12 | 37037605 | VALVE SPRING - INNER (#37037605) |
| 13 | 01038060 | Upper Cup (#01038060) |
| 14 | 01038160 | Valve Half-Cone (#01038160) |
| 15 | 12022600 | PLUG (#12022600) |
| 16 | 90706203 | O RING (#90706203) |
| 17 | 05025331 | Rubber Spacer (#05025331) |
| 18 | 91110506 | SPACER (#91110506) |
| 19 | 96508040 | STUD (#96508040) |
| 20 | 03022055 | Gasket (#03022055) |
| 21 | AP8152268 | Hex Socket Screw` (#AP8152268) |
| 22 | 14034865 | SUPPORT (#14034865) |
| 23 | 92603010 | NUT A (#92603010) |
| 24 | 14018400 | WASHER (#14018400) |
| 25 | 14030201 | ROCKER ARM B (#14030201) |
| 26 | 14030401 | ROCKER ARM A (#14030401) |
| 27 | 91111511 | ROCK.ARM BSHG. (#91111511) |
| 28 | 17034050 | ADJ.SCREW (#17034050) |
| 29 | 10034100 | ROCKER ARM ADJUSTER NUT (#10034100) |
| 30 | 94322215 | SPRING-ROCKER (#94322215) |
| 31 | 90118152 | WASHER (#90118152) |
| 32 | 10032700 | WASHER (#10032700) |
| 33 | 12031800 | ROCKER SPINDLE (#12031800) |
| 34 | 98084316 | Screw (#98084316) |
| 35 | 95120065 | WASHER (#95120065) |
| 36 | 06023500 | HEAD COVER (#06023500) |
| 37 | 06941000 | INSERT (#06941000) |
| 38 | 976139 | GASKET, VALVE COVER (#976139) |
| 39 | 05025932 | VITE TBEI IX M6X50 COPERCHIO TESTA (#05025932) |
| 40 | 01037030 | LOWER CUP (#01037030) |
| 41 | 95129180 | WAVE WASHER (#95129180) |
| 42 | 05021831 | Screw (#05021831) |
| 42 | 976144 | Screw (#976144) |
| 43 | 06023400 | HEAD GUARD GRISO (#06023400) |
| 44 | 05025931 | SCREW (#05025931) |
| 45 | 91120617 | BUSHING (#91120617) |
| 46 | 90706094 | O RING-VITON (#90706094) |
