2006 2007 Breva V ie 850 Stands
| Position | Part Number | Description |
|---|---|---|
| 1 | 05430330 | Central Stand (#05430330) |
| 2 | ||
| 3 | AP8178918 | Stand Spring Protection (#AP8178918) |
| 4 | AP8221317 | Lateral Stand Spring (#AP8221317) |
| 5 | AP8221318 | Internal Lateral Stand Spring (#AP8221318) |
| 6 | 05432930 | Rh Plate (#05432930) |
| 7 | 05433430 | Lh Plate (#05433430) |
| 8 | 98682530 | Screw (#98682530) USE AP8150195 |
| 9 | 05429630 | BUSHING (#05429630) |
| 10 | 05432130 | Lateral Stand (#05432130) |
| 10 | 977079 | 1200 SPORT STAND (#977079) |
| 11 | 05433630 | Stand Plate (#05433630) |
| 12 | AP8127319 | ROTARY SWITCH (AP8127319) (#AP8127319) |
| 13 | AP8152279 | Screw w/flange (#AP8152279) |
| 14 | AP8150015 | Washer 6,6x18x1,6* (#AP8150015) |
| 15 | AP8121994 | Central stand fixing bolt (#AP8121994) |
| 16 | AP8152001 | Lower Nut (#AP8152001) |
| 17 | AP8102524 | Stand Spring Protection (#AP8102524) |
| 18 | AP8221204 | Lateral Stand Spring (#AP8221204) |
| 19 | AP8221211 | Internal Lateral Stand Spring (#AP8221211) |
| 20 | 98231235 | Hex Socket Screw (#98231235) |
| 21 | AP8144030 | Stand end stop (#AP8144030) |
| 22 | AP8150292 | Curved Spring Washer (#AP8150292) |
| 23 | 00823923140 | THERMAL SHEATH (#00823923140) |
| 24 | 14609650 | TIE WRAP (#14609650) |
| 25 | 95008313 | Washer, 13X24X2.5 (#95008313) |
| 26 | 977292 | ADATTATORE INT. CAVAL 1100 (#977292) |
| 26 | 977571 | Adapter cable (#977571) |
| 27 | 977080 | Stand plate (#977080) |
| 28 | 639542 | SIDESTAND SWITCH (#639542) |
| 29 | 98612216 | ALLEN BOLT (#98612216) |
| 30 | 95020105 | WASHER (#95020105) |
| 31 | 30217900 | LOCK WASHER (#30217900) |
