2006 2007 Breva V ie 850 Throttle Body
| Position | Part Number | Description |
|---|---|---|
| 1 | 05112530 | Throttle Assy. (#05112530) |
| 2 | 05112830 | Potentiometer (#05112830) |
| 3 | 05115030 | Rh Manifold (#05115030) |
| 4 | 05115730 | Injector Kit Complete (#05115730) |
| 5 | 93305058 | Hose Clamp (#93305058) |
| 6 | 05114430 | Intake Hose (#05114430) |
| 7 | 90706461 | O RING 46, 04X3, 53 VITON (#90706461) |
| 8 | 05115031 | Lh Manifold (#05115031) |
| 9 | 98682325 | BOLT (#98682325) |
| 10 | 95008206 | WASHER (#95008206) |
| 11 | 98350310 | Screw (#98350310) |
| 12 | 95100116 | WASHER (#95100116) |
| 13 | 93305057 | CLAMP (#93305057) |
| 14 | 01114390 | INTAKE BOOT (#01114390) |
| 15 | 93305061 | CLAMP (#93305061) |
| 16 | 31576183 | Spacer (#31576183) |
| 17 | AP8120428 | Upper cable-guide (#AP8120428) |
| 18 | 05135830 | Min.regulation engine (#05135830) |
