2006 2007 Griso V ie 850 Clutch
| Position | Part Number | Description |
|---|---|---|
| 1 | 04084100 | CLUTCH SPRING (#04084100) |
| 1 | 13084100 | CLUTCH SPRING (#13084100) |
| 2 | 30082900 | PRESSURE PLATE (#30082900) |
| 3 | 05084430 | CLUTCH PLATE DEEP SPLINE (#05084430) |
| 4 | 12082300 | CLUTCH INTERMEDIATE PLATE (#12082300) |
| 5 | 04082800 | CUP (#04082800) |
| 6 | 05085730 | Rod (#05085730) |
| 7 | 14085900 | CLUTCH PUSH ROD SEAL (TAKES 2) (#14085900) |
| 8 | 14086000 | INNER CLUTCH BODY (#14086000) |
| 9 | 12087001 | THROWOUT BEARING 5 SPEED (12087001) |
| 10 | 04086100 | CLUTCH CYLINDER (#04086100) |
| 11 | 90706170 | O RING (#90706170) |
| 12 | 05217630 | Bush (#05217630) |
| 13 | 05086330 | Clutch Command Cylinder (#05086330) |
| 14 | AP8152278 | #12 Screw w/ flange M6x16* (#AP8152278 ) |
