2006 2007 Griso V ie 850 Oil Pump II
| Position | Part Number | Description |
|---|---|---|
| 1 | 976134 | OIL PUMP (#976134) |
| 2 | 277916 | DOWEL (#277916) |
| 3 | 976165 | Needle bearing (#976165) |
| 4 | 13148300 | KEY SQUARE STOCK (#13148300) |
| 5 | 98350330 | Hex Socket Screw (#98350330) |
| 6 | 976448 | Washer (#976448) |
| 7 | 30147700 | PUMP GEAR HD (#30147700) |
| 8 | 92602510 | NUT (#92602510) |
| 9 | 19149800 | WASHER (#19149800) USE AP8152220 |
| 10 | 05153630 | Pipe (#05153630) |
| 11 | 25656102 | GASKET (#25656102) |
| 12 | 95990037 | BANJO BOLT (#95990037) |
| 13 | 12154200 | OIL LINE CRUSH WASHER (#12154200) |
| 14 | 31768780 | Pressure Sensor (#31768780) USE 1D001138 |
| 15 | 976168 | Needle bearing (#976168) |
| 16 | 12006400 | ALUM CRUSH WASHER (#12006400) |
| 17 | 976688 | PRESSURE OIL SENSOR CAP (#976688) |
