2006 2007 Sport 1200 1200 Crank Shaft Cpl
| Position | Part Number | Description |
|---|---|---|
| 1 | 976182 | Cylinder with piston (#976182) |
| 2 | 976069 | PISTON & RINGS FOR 1 CYL Breva Sport and Norge 1200 (#976069) |
| 3 | 976183 | KIT FASCE ELASTICHE (#976183) |
| 4 | 976070 | Piston ring (#976070) |
| 5 | 976071 | Piston Ring (#976071) |
| 6 | 976072 | Piston ring (#976072) |
| 7 | 30061241 | WRIST PIN (#30061241) |
| 8 | 874567 | Circlip (#874567) |
| 9 | 976064 | BASE GASKET (#976064) |
| 10 | 37067705 | ALLEN BOLT (#37067705) USE 122675 |
| 11 | 14217901 | LOCK WASHER (#14217901) USE AP8152105 |
| 12 | 976031 | Stud bolt (#976031) |
| 13 | 05061530 | Connecting Rod Cpl. (#05061530) |
| 13 | 976003 | CON ROD (#976003) |
| 14 | 01062230 | Bolt, Conrod (#01062230) |
| 14 | 849131 | CONROD SCREW (#849131) |
| 15 | 91112128 | BUSH-CON ROD (#91112128) |
| 16 | 01062030 | Bearing, Half (#01062030) |
| 16 | 01062031 | Bearing half-shell min.0,254 (#01062031) |
| 16 | 01062032 | Bearing half-shell min.0,508 (#01062032) |
| 16 | 01062033 | Bearing half-shell min.0,762 (#01062033) |
| 16 | 976171 | Bearing, Half (#976171) |
| 16 | 976172 | Bearing, Half (#976172) |
| 17 | 976118 | Crankshaft cpl. (#976118) |
| 17 | 976187 | Crankshaft cpl. (#976187) |
| 18 | 37065405 | CRANK PLUG (#37065405) |
| 19 | 04067000 | FLYWHEEL (#04067000) |
| 20 | 12067701 | SCREW (#12067701) use 597150 |
| 21 | 14615901 | WASHER (#14615901) |
| 22 | 01067930 | RING GEAR (#01067930) |
| 23 | 05025330 | Rubber Spacer (#05025330) |
| 24 | 825597 | Nozzle for carter (#825597) |
