2006 2007 Sport 1200 1200 Saddle Central Bod
| Position | Part Number | Description |
|---|---|---|
| 1 | 977831 | 1200 SPORT SEAT (#977831) |
| 2 | 05570230 | Rh Body Panel Blank (#05570230) |
| 2 | 05570231 | Rh Side Panel, Red (#05570231) |
| 2 | 05570232 | Rh Side Panel, Black (#05570232) |
| 3 | AP8144538 | Gasket (#AP8144538) |
| 4 | AP8152339 | SCREW W/FLANGE (#AP8152339) |
| 5 | 05570430 | LH body panel blank (#05570430) |
| 5 | 05570431 | Lh Side Panel, Red (#05570431) |
| 5 | 05570432 | Lh Side Panel, Black (#05570432) |
| 6 | 05466830 | Saddle Lock (#05466830) |
| 7 | AP8102914 | Lock cable (#AP8102914) |
| 8 | AP8102913 | Pass.saddle connecti (#AP8102913) |
| 9 | 98370625 | ALLEN SCREW (#98370625) USE STAB6X25 |
| 10 | AP8152299 | Self-Locking Nut (#AP8152299) |
| 11 | AP8102523 | Lock nut (#AP8102523) |
| 12 | AP8102502 | Helmet lock cable (#AP8102502) |
| 13 | 05573830 | RH side fairing decal (#05573830) |
| 14 | 05573831 | DECAL (#05573831) |
| 15 | 32461810 | Saddle rubber (#32461810) |
| 16 | 32461610 | Rubber Spacer - Nevada (#32461610) |
| 17 | 977754 | COPERTURA SELLA GREZZA (#977754) |
| 17 | 977754Y01 | Cover pillion rider seat red (#977754Y01) |
| 17 | 977754Y02 | Saddle cover, black (#977754Y02) |
| 18 | 98370616 | BOLT (#98370616) |
