2006 2008 California Classic touring 1100 Rear Mudguard
| Position | Part Number | Description |
|---|---|---|
| 1 | 03437110 | REAR FENDER BARE (#03437110) |
| 1 | 03437112 | REAR FENDER BLACK (#03437112) |
| 1 | 03437113 | REAR FENDER VINTAGE RED (#03437113) |
| 1 | 977231 | Rear mudguard, red (#977231) |
| 1 | 977232 | Rear mudguard, white /g. (#977232) |
| 2 | 95008206 | WASHER (#95008206) |
| 3 | 00155930171 | Gasket (#00155930171) |
| 4 | 91551099 | RUBBER (#91551099) |
| 5 | 92650036 | Flanged Nut (#92650036) |
| 6 | 03437430 | FENDER MOUNT A (#03437430) |
| 7 | 98223835 | Bolt, backrest pivot (#98223835) |
| 8 | 95005312 | Washer, 8.5x24x2 (#95005312) |
| 9 | 92787008 | NUT (#92787008) USE 860651 |
| 10 | 03438030 | MUDGUARD A (#03438030) |
| 11 | 98350325 | Hex Socket Screw (#98350325) |
| 12 | 95005320 | WASHER (#95005320) |
| 13 | 92630106 | NUT USE 92630707 (#92630106) |
| 14 | 98682325 | BOLT (#98682325) |
| 15 | 03578730 | SPACER (#03578730) |
