2006 2010 California Vintage 1100 Frame
| Position | Part Number | Description |
|---|---|---|
| 1 | 977200 | Frame (#977200) |
| 2 | 93180216 | RUBBER PLUG (#93180216) |
| 3 | 03469200 | SPACER LH A (#03469200) |
| 4 | 98683635 | Screw 12X35 (#98683635) |
| 5 | 95022112 | Washer (#95022112) |
| 6 | 92606312 | Nut (#92606312) |
| 7 | 92660601 | CAGE NUT (#92660601) |
| 8 | ||
| 9 | 29418360 | BATTERY PLATE (#29418360) |
| 10 | 98370616 | BOLT (#98370616) |
| 11 | 95008208 | WASHER (#95008208) |
| 12 | 30970200 | PLASTIC COVER A (#30970200) |
| 13 | 977163 | Clamp (#977163) |
| 14 | 39103400 | RUBBER PAD FOR GAS TANK (#39103400) |
| 16 | 39103500 | PLATE (#39103500) |
| 17 | 00823931080 | PVC GASKET (#00823931080) |
| 18 | 03013800 | WAVE WASHER (#03013800) |
| 19 | AP8152299 | Self-Locking Nut (#AP8152299) |
| 20 | 03479545 | TOOL TRAY (#03479545) |
| 21 | 30461360 | BRACKET (#30461360) use 304613605 |
| 22 | 98350416 | Screw (#98350416) |
| 23 | 98682420 | Screw (#98682420) |
| 24 | 03462345 | SEAT BRACKET EV KING/QUEEN (#03462345) |
| 25 | 30462060 | SEAT LOCK ASSY (#30462060) |
| 26 | 92650036 | Flanged Nut (#92650036) |
| 27 | 19705900 | PLUG (#19705900) |
| 28 | 98350312 | CLUTCH MOUNT SCREW (#98350312) |
| 29 | 977384 | Saddle release cable (#977384) |
| 30 | 95522508 | SPRING PIN (#95522508) |
| 31 | 98370630 | Hex socket screw M6X30 (#98370630) |
| 32 | 28576591 | CLIP (#28576591) |
