2006 2010 California Vintage 1100 Generator Regulator
| Position | Part Number | Description |
|---|---|---|
| 1 | 32712411 | GENERATOR (#32712411) |
| 1 | 883877 | ALTERNATOR (#883877) |
| 1 | 884170 | Generator (#884170) |
| 2 | 32703810 | REGULATOR (#32703810) |
| 2 | 883878 | Regulator (#883878) |
| 3 | 30714201 | WASHER (#30714201) |
| 4 | 92606516 | Nut (#92606516) |
| 5 | 29711460 | FRONT COVER (#29711460) |
| 6 | 98680265 | Screw (#98680265) |
| 7 | 29217960 | WASHER (#29217960) |
| 8 | 90706178 | O RING (#90706178) |
| 9 | 37712306 | SPACER (#37712306) |
| 10 | 91600450 | WOODRUFF KEY (#91600450) |
| 11 | 29711960 | REAR COVER (#29711960) |
| 12 | AP8152282 | Screw w/ flange M6x3 (#AP8152282) |
| 13 | 95100141 | WASHER (#95100141) |
| 14 | 28576591 | CLIP (#28576591) |
