2006 2010 California Vintage 1100 Luggage Rack Cases Bracket
| Position | Part Number | Description |
|---|---|---|
| 1 | 977810 | Rear bumper (#977810) |
| 2 | 92640708 | DADO IX NY M8X8,3 BASSO (#92640708) |
| 3 | 14615901 | WASHER (#14615901) |
| 4 | 92640408 | NUT IX NY M8X10,4 Aisi 304-DIN A2 (#92640408) |
| 5 | 977040 | RH support (#977040) |
| 6 | 977039 | LH support (#977039) |
| 7 | 98692430 | Hex Socket Screw M8X30 (#98692430) |
| 8 | 977019 | Rear bumper (#977019) |
| 9 | 977256 | RH support (#977256) |
| 10 | 977257 | LH support (#977257) |
| 11 | 98230817 | Hex socket screw M8x16 (#98230817) |
| 12 | 977192 | Rear handle (#977192) |
| 13 | 977416 | Luggage rack (#977416) |
| 14 | 98692313 | Hex Socket Screw M6X12 (#98692313) |
| 15 | 03013800 | WAVE WASHER (#03013800) |
| 16 | 98692325 | BOLT (#98692325) |
| 17 | 95005312 | Washer, 8.5x24x2 (#95005312) |
