2006 2010 California Vintage 1100 Rear Mudguard
| Position | Part Number | Description |
|---|---|---|
| 1 | 883173 | Rear mudguard (#883173) |
| 1 | 88317300BM | Rear mudguard, white (#88317300BM) |
| 1 | 88761400Z1 | Rear mudguard (#88761400Z1) |
| 1 | 977155 | REAR FENDER-CHROME (#977155) |
| 2 | 91551099 | RUBBER (#91551099) |
| 3 | 98370850 | Screw (#98370850) |
| 4 | 14615901 | WASHER (#14615901) |
| 5 | 03435550 | SPACER, REAR FENDER (#03435550) |
| 6 | 95008208 | WASHER (#95008208) |
| 7 | 92787008 | NUT (#92787008) USE 860651 |
| 8 | AP8258253 | (#AP8258253) |
| 9 | AP8224164 | Rear Reflector, Red (#AP8224164) |
| 10 | AP8152306 | Self-Locking Nut (#AP8152306) |
| 11 | AP8149034 | Number Plate Holder (#AP8149034) |
| 12 | 98230518 | Screw (#98230518) |
| 13 | AP8150248 | Washer 5.5mm x 15mm x 1.6 mm (#AP8150248) |
