2006 2010 California Vintage 1100 Toe Guard Front Bumpers

Position Part Number Description
1 883167 RH toe guard white (#883167)
1 88316700YA3 RH toe guard (#88316700YA3)
1 88410600YR3 RH protection (#88410600YR3)
1 977184 TOE GUARD LH BLACK (#977184)
2 93231605 FASTENER (#93231605)
3 98370520 BOLT (#98370530)
4
5 883166 LH toe guard white (#883166)
5 88316600YA3 LH toe guard (#88316600YA3)
5 88410700YR3 LH toe guard black (#88410700YR3)
5 977183 TOE GUARD RH BLACK (#977183)
6 884062 RH front bumper (#884062)
6 977002 ENGINE GUARD RH (#977002)
7 977193 Fixing plate (#977193)
8 884063 LH front bumper (#884063)
8 977189 LH front bumper (#977189)
9 98682414 Hex Socket Screw (#98682414)
10 14615901 WASHER (#14615901)
11 91180842 SPACER (#91180842)
12 92640408 NUT IX NY M8X10,4 Aisi 304-DIN A2 (#92640408)
13 98370825 Hex Socket Screw (#98370825)
14 17451750 PLATE (#17451750)
15 977044 RH protection (#977044)
16 977045 LH protection (#977045)
17 18941750 RUBBER PAD (#18941750)
18 88406000YR3 LH toe guard black (#88406000YR3)
19 88406100YR3 LH toe guard black (#88406100YR3)
20 884064 Kit sirene cromate (#884064)
