2007 2009 Bellagio 940 Crankshaft Cpl
| Position | Part Number | Description |
|---|---|---|
| 1 | 981002 | Cylinder with piston (#981002) |
| 2 | 976371 | Piston assy D.95 (#976371) |
| 3 | 976183 | KIT FASCE ELASTICHE (#976183) |
| 4 | 976070 | Piston ring (#976070) |
| 5 | 976071 | Piston Ring (#976071) |
| 6 | 976072 | Piston ring (#976072) |
| 7 | 30061241 | WRIST PIN (#30061241) |
| 8 | 90351039 | Stop ring (#90351039) |
| 9 | 976064 | BASE GASKET (#976064) |
| 10 | 37067705 | ALLEN BOLT (#37067705) USE 122675 |
| 11 | 14217901 | LOCK WASHER (#14217901) USE AP8152105 |
| 12 | 976031 | Stud bolt (#976031) |
| 13 | 976006 | Connecting rod cpl. (#976006) |
| 14 | 849131 | CONROD SCREW (#849131) |
| 16 | 976171 | Bearing, Half (#976171) |
| 16 | 976172 | Bearing, Half (#976172) |
| 17 | 976425 | Crankshaft cpl. (#976425) |
| 18 | 976020 | Plug (#976020) |
| 19 | 04067000 | FLYWHEEL (#04067000) |
| 20 | 976481 | SCREW TE FL DA (#976481) |
| 21 | 976484 | Axle Washer (#976484) |
| 22 | 01067930 | RING GEAR (#01067930) |
| 23 | 05025330 | Rubber Spacer (#05025330) |
| 24 | 825597 | Nozzle for carter (#825597) |
