2007 2009 Bellagio 940 Foot Rests I
| Position | Part Number | Description |
|---|---|---|
| 1 | 978224 | RH front footrest bracket (#978224) |
| 2 | 98680465 | SCREW (#98680465) |
| 3 | 98710215 | SCREW (#98710215) |
| 4 | 978225 | LH front footrest bracket (#978225) |
| 5 | AP8145034 | FOOT PEG RH (#AP8145034) |
| 6 | 32443210 | PEG RUBBER- BREVA (#32443210) |
| 7 | 32441210 | Plate - Breva (#32441210) |
| 8 | AP8221277 | FOOT PEG SPRING (#AP8221277) |
| 9 | AP8152277 | Screw w/flange (#AP8152277) |
| 10 | AP8121567 | Pin (#AP8121567) |
| 11 | AP8152409 | STOP RING (#AP8152409) |
| 12 | ||
| 13 | 32443211 | Support Rubber Part - Breva (#32443211) |
| 14 | 978472 | Guard (#978472) |
