2007 2009 Bellagio 940 Rear Brake Caliper
| Position | Part Number | Description |
|---|---|---|
| 1 | 978414 | REAR BRAKE CALIPER (#978414) |
| 2 | AP8152320 | Screw w/ flange M10x (#AP8152320) |
| 3 | 05654630 | Rear Brake Pads (#05654630) |
| 4 | 05659130 | Pin+Split Pin (#05659130) |
| 5 | 05659030 | SPRING (#05659030) |
| 6 | ||
| 7 | AP8133597 | Bored screw (#AP8133597) |
| 8 | AP8133595 | Air bleed valve (#AP8133595) |
| 9 | AP8133596 | Bleed valve cap 20 pc. (#AP8133596) |
| 10 | 978364 | Rear brake hose (#978364) |
| 11 | AP8133962 | SELVAGE M10x1 (#AP8133962) |
| 12 | AP8202238 | Cable-guide hook (#AP8202238) |
| 13 | AP8201808 | Cable-guide D8 (#AP8201808) |
