2007 2009 Bellagio 940 Throttle Body
| Position | Part Number | Description |
|---|---|---|
| 1 | 03112560 | Throttle Assembly (#03112560) |
| 2 | 01530504 | INJECTOR KIT (#01530504) |
| 3 | 01530500 | POTENTIOMETER OR THROTTLE POSITION SENSOR (#01530500) |
| 4 | 29530562 | Throttle Rod (#29530562) |
| 5 | 30114470 | SLEEVE FI (#30114470) |
| 6 | 93305061 | CLAMP (#93305061) |
| 7 | 03114370 | SLEEVE FI (#03114370) |
| 8 | 976026 | RH manifold (#976026) |
| 9 | 976049 | LH manifold (#976049) |
| 10 | 98682325 | BOLT (#98682325) |
| 11 | 14217901 | LOCK WASHER (#14217901) USE AP8152105 |
| 12 | 98310609 | Screw (#98310609) |
| 13 | 95100116 | WASHER (#95100116) |
| 14 | 90706461 | O RING 46, 04X3, 53 VITON (#90706461) |
| 15 | AP8120405 | Rubber spacer * (#AP8120405) |
| 16 | 977476 | Pin (#977476) |
| 17 | 95129100 | WASHER (#95129100) |
| 18 | 977180 | COVER, RH CHROME PLATED PLASTIC (#977180) |
| 18 | 978390 | RH cover black (#978390) |
| 19 | 977181 | COVER, LH CHROME PLATED PLASTIC (#977181) |
| 19 | 978391 | LH cover black (#978391) |
| 20 | 98370520 | BOLT (#98370520) |
| 21 | 30577800 | NYLON WASHER (#30577800) |
| 22 | 93232005 | Vibration Damper Pad (#93232005) |
