2007 Breva 1200 1200 Front Body Duct
| Position | Part Number | Description |
|---|---|---|
| 1 | 05576631 | Rh Protection (#05576631) |
| 2 | 05576230 | RH LATERAL FAIRING, BLA (#05576230) |
| 2 | 05576231 | Rh Lateral Fairing, Technogray (#05576231) |
| 3 | AP8150413 | Self-Tap Screw (#AP8150413) |
| 4 | 05576330 | LH LATERAL FAIRING, BLA (#05576330) |
| 4 | 05576331 | Lh Lateral Fairing, Technogray (#05576331) |
| 5 | AP8152339 | SCREW W/FLANGE (#AP8152339) |
| 6 | 05576731 | Lh Protection (#05576731) |
| 7 | 05476430 | Water Cooler Grille (#05476430) |
| 8 | AP8152302 | SCREW W/ FLANGE (#AP8152302) USE 2B014101 |
| 9 | AP8102375 | Clip (#AP8102375) |
| 10 | 92787205 | NUT (#92787205) |
| 11 | 95005304 | Washer (#95005304) |
