2007 Breva 1200 1200 Front Mud Pillar
| Position | Part Number | Description |
|---|---|---|
| 1 | 05434330 | FRONT MUDGUARD BLANK (#05434330) |
| 1 | 05434330F2 | NORGE/BREVA GREY FRONT FENDER (#05434330F2) |
| 1 | 05434330ND | Front mudguard, black (#05434330ND) |
| 1 | 05434330Y01 | Front mudguard, red (#05434330Y01) |
| 2 | AP8152302 | SCREW W/ FLANGE (#AP8152302) USE 2B014101 |
| 3 | AP8102375 | Clip (#AP8102375) |
| 4 | 05570530 | Rh Pillar (#05570530) |
| 5 | 05570630 | Lh Pillar (#05570630) |
| 7 | AP8152339 | SCREW W/FLANGE (#AP8152339) |
| 8 | AP8152287 | Screw w/flange (#AP8152287) |
| 9 | AP8221128 | T. Bushing (#AP8221128) |
| 10 | AP8120594 | Silent-block (#AP8120594) |
| 11 | 95008308 | Washer (#95008308) |
