2007 Breva 1200 1200 Oil Radiator
| Position | Part Number | Description |
|---|---|---|
| 1 | 05162031 | Oil Radiator (#05162031) |
| 2 | 01154230 | GASKET (#01154230) |
| 3 | 01161331 | REDUCER (#01161331) |
| 4 | 05162331 | PIPE, RH (#05162331) |
| 5 | 05161631 | PIPE, LH (#05161631) |
| 6 | AP8101372 | SILENT-BLOCK (#AP8101372) |
| 7 | 05164630 | Special Screw (#05164630) |
| 8 | 91551010 | GROMMET (#91551010) |
| 9 | 95005304 | Washer (#95005304) |
| 10 | 92787205 | NUT (#92787205) |
| 11 | 05164230 | Clamp (#05164230) |
| 12 | 98680340 | Screw (#98680340) |
| 13 | 95005306 | WASHER (#95005306) |
| 14 | 91120622 | Bush 6, 2X11X22,5 (#91120622) |
