2007 Norge 850 850 Front Fork
| Position | Part Number | Description |
|---|---|---|
| 1 | 05490230 | Front Fork Marzocchi (#05490230) |
| 2 | 05490630 | Rh Sleeve (#05490630) |
| 3 | 05490730 | Lh Sleeve (#05490730) |
| 4 | 03530528 | BUSHING-UPPER (#03530528) USE AP8163093 |
| 5 | 03530527 | SPACER A (#03530527) |
| 6 | 03530526 | FORK SEAL (#03530526) Fork seal/dust cover kit use 03530000. |
| 7 | 03530525 | CIRCLIP (#03530525) |
| 8 | 03530524 | DUST SEAL (#03530524) for Fork seal/dust cover use 03530000 |
| 9 | 03530551 | PLUG (#03530551) |
| 10 | 05530535 | Ros Rame 10.5X14X1.5 (#05530535) |
| 11 | 98682535 | Hex socket screw M10x35 (#98682535) |
| 12 | 01530501 | Dowel (#01530501) |
| 13 | 05504530 | Plug Cpl. (#05504530) |
| 14 | 03530553 | SPRING (#03530553) |
| 15 | 05530530 | Plunger, Complete (#05530530) |
| 16 | 03530550 | RING (#03530550) |
| 17 | ||
| 18 | 05525430 | Sleeve (#05525430) |
| 19 | 05530531 | Preload Tube (#05530531) |
| 20 | 05526630 | Spring (#05526630) |
| 21 | 90271016 | Stop Ring (#90271016) |
| 22 | 05530532 | Bush (#05530532) |
| 23 | 05530533 | Nut (#05530533) |
| 24 | 01530503 | Thrust Plate (#01530503) |
| 25 | 05530536 | O-Ring (#05530536) |
| 27 | 01530509 | O-ring (#01530509) |
| 28 | 05530534 | Adjusting Pin (#05530534) |
| 29 | 98680340 | Screw (#98680340) |
