2009 2010 Stelvio 1200 NTX ABS 1200 Frame Electrical System I
| Position | Part Number | Description |
|---|---|---|
| - | 1722700 | #20 Gasket 0,3mm (#1722700) |
| - | 1722701 | #17 Gasket 0,4mm (#1722701) |
| - | 1722702 | #20 Gasket 0,6mm (#1722702) |
| - | 1722703 | #20 Gasket 0,8mm (#1722703) |
| - | 1722705 | #20 Gasket 1,5mm (#1722705) |
| - | 5717030 | #14 Spark plug NGK PMR8B (#5717030) |
| - | 14609650 | TIE WRAP (#14609650) |
| - | 29722760 | SENSOR GASKET (#29722760) |
| - | 883224 | Harness-Main (#883224) |
| - | 883653 | ECU (#883653) |
| - | 895481 | Starter relay (#895481) |
| - | 93304360 | FASC FISS TUBO 7.6X380 (#93304360) |
| - | 93304390 | TIE WRAP (#93304390) |
| - | 977769 | Fuse 3A (#977769) |
| - | 977771 | Fuse 10A (#977771) |
| - | 978448 | WIRE HARNESS MAIN (#978448) |
| - | ||
| 1 | 886161 | Main wiring harness (#886161) |
| 2 | 883408 | ECU (#883408) |
| 3 | 978152 | RUBBER (#978152) |
| 4 | ||
| 5 | 98690245 | Screw, Tank Pad (#98690245) |
| 6 | 30716500 | IGNITION COIL (#30716500) |
| 7 | 5716730 | #09 Coil holder (#5716730) |
| 8 | 98682125 | Screw (#98682125) |
| 9 | 95008204 | Washer (#95008204) |
| 10 | 92630104 | NUT (#92630104) |
| 11 | 883028 | HT wire (#883028) |
| 12 | 639687 | SPARK PLUG CR8EKB (NGK) (#639687) |
| 13 | ||
| 14 | ||
| 15 | ||
| 16 | ||
| 17 | ||
| 18 | ||
| 19 | 977772 | Fuse 15A (#977772) |
| 20 | ||
| 21 | 1721600 | #16 Phase/revolution sensor (#1721600) |
| 22 | 847180 | O-RING (#847180) |
| 23 | 1722704 | #17 Gasket 1mm (#1722704) |
| 24 | 98682212 | Hex Socket Screw (#98682212) |
| 25 | 95008205 | Washer 5.3mm (#95008205) |
| 26 | 29729461 | OIL TEMP SENSOR (#29729461) |
| 27 | 976556 | Support (#976556) |
| 28 | 98683520 | SCREW (#98683520) |
| 29 | ||
| 30 | ||
| 31 | ||
| 32 | 49609601 | TIE STRAP (#49609601) |
| 33 | ||
| 35 | ||
| 36 | 95100059 | WASHER (#95100059) |
| 37 | ||
| 38 | ||
| 39 | ||
| 40 | 883148 | Plate (#883148) |
| 41 | ||
| 42 | 883968 | Guard (#883968) |
