2009 2011 California Black Eagle 1100 Lh Front Brake System
| Position | Part Number | Description |
|---|---|---|
| 1 | 977169 | LH front brake caliper, black (#977169) |
| 2 | 98683530 | Bolt, Caliper (#98683530) |
| 3 | 19149800 | WASHER (#19149800) USE AP8152220 |
| 4 | 01659131 | FRT CALIPER SPRING (#01659131) |
| 5 | 05659230 | Spurgo-Cappuccio (#05659230) |
| 6 | 01659130 | BLEEDING PAD PIN (#01659130) |
| 7 | AP8133594 | Oil pipe screw (#AP8133594) |
| 8 | 03658330 | FASCETTA LUNGA (#03658330) |
| 9 | 03658201 | BUSHING (#03658201) |
| 10 | 98257410 | Screw (#98257410) |
| 11 | 92630104 | NUT (#92630104) |
| 12 | 98350315 | Screw (#98350315) |
| 13 | 03013800 | WAVE WASHER (#03013800) |
| 14 | 91551120 | GROMMET (#91551120) |
| 15 | 14609650 | TIE WRAP (#14609650) |
| 16 | 977369 | Pipe (#977369) |
| 17 | 01654630 | BRAKE PADS, PR (#01654630) |
| 18 | 25656100 | WASHER, ALUMINUM (#25656100) |
