2009 2011 California Black Eagle 1100 Saddle Central Bod
| Position | Part Number | Description |
|---|---|---|
| 1 | 883113 | CALIFORNIA SEAT (#883113) |
| 2 | 03476206 | RH Sidecover, Blank (#03476206) |
| 2 | 88618800NG | RH side panel (#88618800NG) |
| 3 | 98370616 | BOLT (#98370616) |
| 4 | 66478610 | WASHER (#66478610) |
| 5 | 92660601 | CAGE NUT (#92660601) |
| 6 | 03476306 | SIDE COVER LH BARE (#03476306) |
| 6 | 88618900NG | LH side panel (#88618900NG) |
| 7 | 03467347 | REAR FRAME COVER (#03467347) |
| 8 | 03461147 | SEAT PIN (#03461147) |
| 9 | 91180605 | SPACER (#91180605) |
| 10 | 92650036 | Flanged Nut (#92650036) |
| 12 | 95005307 | Washer (#95005307) |
| 13 | 977192 | Rear handle (#977192) |
| 14 | 98692430 | Hex Socket Screw M8X30 (#98692430) |
