| Position |
Part Number |
Description |
| 1 |
B013661
|
SHEET (#B013661) |
| 2 |
CM162701
|
CALIBRATED RING 1.02 (#CM162701) |
| 2 |
CM162702
|
CALIBRATED RING 1.05 (#CM162702) |
| 2 |
CM162703
|
CALIBRATED RING 1.08 (#CM162703) |
| 2 |
CM162704
|
CALIBRATED RING 1.11 (#CM162704) |
| 2 |
CM162705
|
CALIBRATED RING 1.11 (#CM162705) |
| 3 |
874621
|
Gasket (#874621) |
| 3 |
874622
|
GASKET (#874622) |
| 3 |
976311
|
CYLINDER HEAD GASKET (#976311) |
| 4 |
880879
|
RH.Rocker arm support (#880879) |
| 5 |
015792
|
SCREW (#015792) |
| 6 |
872759
|
Dowel (#872759) |
| 7 |
833520
|
NUT FOR REAR SUSP.BRACKET (BV-500) (#833520) |
| 8 |
976359
|
ROCKER ASSY (#976359) |
| 8 |
B013603
|
Bilanciere aspirazione sx scarico dx (#B013603) |
| 9 |
976360
|
ROCKER ASSY (#976360) |
| 9 |
B013605
|
Bilanciere aspirazione dx scarico sx (#B013605) |
| 10 |
873850
|
SCREW TIP ASSEMBLY(#873850) |
| 10 |
879707
|
SCREW TIP ASSY (#879707) |
| 11 |
484819
|
NUT (#484819) |
| 11 |
879916
|
LOW HEXAGONAL NUT (#879916) |
| 12 |
873631
|
PUSH ROD ROCKER ARM (#873631) |
| 12 |
B015681
|
PUSH ROD ROCKER ARM (#B015681) |
| 13 |
878751
|
TAPPET (FINISHED) (#878751) |
| 14 |
487444
|
SCREW (#487444) |
| 15 |
976674
|
Flat washer (#976674) |
| 16 |
B014223
|
Camshaft axle with U.P. (#B014223) |
| 17 |
976589
|
REFERENCE DOWELL (#976589) |
| 18 |
976350
|
Ring Gear (#976350) |
| 19 |
2A000080
|
Blow-by centrifugal separator (#2A000080) |
| 19 |
874601
|
SHEET OIL BREATHER (#874601) |
| 20 |
843060
|
FLANGED HEXAGONAL HEAD SCREW (#843060) |
| 21 |
880965
|
Gasket ring (#880965) |
| 22 |
2A000082
|
Oil breather cover (#2A000082) |
| 22 |
B013479
|
TIMING SYSTEM COVER (#B013479) |
| 23 |
B016796
|
CONVEX HEAD SCREW TORX M5X16 (#B016796) |
| 24 |
976341
|
TIMING CHAIN (#976341) |
| 25 |
976338
|
Chain Guide Plate (#976338) |
| 26 |
976337
|
MOBILE SLIDING SHOE (#976337) |
| 27 |
878868
|
SCREW SPACER FOR CHAIN TIGHTENING ROD (#878868) |
| 28 |
873689
|
CHAIN TENSIONER HYDRAULIC RH (#873689) |
| 29 |
| 30 |
872741
|
LH V/C GASKET 1200 (#872741) |
| 31 |
872742
|
RH V/C GASKET 1200 (#872742) |
| 32 |
880127
|
CYLINDER HEAD COVER GASKET RIGHT (#880127) |
| 33 |
1A002061
|
Rockers axle support (#1A002061) |
| 34 |
1A002062
|
Rockers axle support (#1A002062) |
| 35 |
1A006716
|
BUFFER DAMPER 1A006716 (#1A006716) |
| 36 |
873626
|
O RING (#873626) |
