2011 2013 Stelvio 1200 8v Std NTX Engine Rh Cylinder Timing System Bowl
| Position | Part Number | Description |
|---|---|---|
| - | 873850 | SCREW TIP ASSEMBLY(#873850) |
| - | 874621 | Gasket (#874621) |
| - | 874622 | GASKET (#874622) |
| - | 879916 | LOW HEXAGONAL NUT (#879916) |
| - | 976359 | ROCKER ASSY (#976359) |
| - | ||
| - | ||
| - | CM162701 | CALIBRATED RING 1.02 (#CM162701) |
| - | CM162703 | CALIBRATED RING 1.08 (#CM162703) |
| - | CM162704 | CALIBRATED RING 1.11 (#CM162704) |
| - | CM162705 | CALIBRATED RING 1.11 (#CM162705) |
| 1 | ||
| 2 | CM162702 | CALIBRATED RING 1.05 (#CM162702) |
| 3 | 976311 | CYLINDER HEAD GASKET (#976311) |
| 4 | 880879 | RH.Rocker arm support (#880879) |
| 5 | 15792 | Screw (#15792) |
| 6 | 872759 | Dowel (#872759) |
| 7 | 833520 | NUT FOR REAR SUSP.BRACKET (BV-500) (#833520) |
| 8 | ||
| 9 | 976360 | ROCKER ASSY (#976360) |
| 10 | 879707 | SCREW TIP ASSY (#879707) |
| 11 | 484819 | NUT (#484819) |
| 12 | 873631 | PUSH ROD ROCKER ARM (#873631) |
| 13 | 878751 | TAPPET (FINISHED) (#878751) |
| 14 | 487444 | SCREW (#487444) |
| 15 | 976674 | Flat washer (#976674) |
| 16 | 8792724 | Camshaft (#8792724) |
| 17 | 976589 | REFERENCE DOWELL (#976589) |
| 18 | 976350 | Ring Gear (#976350) |
| 19 | 874601 | SHEET OIL BREATHER (#874601) |
| 20 | 843060 | FLANGED HEXAGONAL HEAD SCREW (#843060) |
| 21 | 880965 | Gasket ring (#880965) |
| 22 | ||
| 23 | 875173 | CONVEX HEAD SCREW WITH TORX IMPRESSION (#875173) |
| 24 | 976341 | TIMING CHAIN (#976341) |
| 25 | 976338 | Chain Guide Plate (#976338) |
| 26 | 976337 | MOBILE SLIDING SHOE (#976337) |
| 27 | 878868 | SCREW SPACER FOR CHAIN TIGHTENING ROD (#878868) |
| 28 | 873689 | CHAIN TENSIONER HYDRAULIC RH (#873689) |
