2011 2013 Stelvio 1200 8v Std NTX Frame Front Body Front Fairing
| Position | Part Number | Description |
|---|---|---|
| - | 887328 | WINDSHIELD (#887328) |
| - | 897641 | SHIELD OF PLASTIC (#897641) |
| - | ||
| 1 | ||
| 2 | 887174 | WINDSHIELD (#887174) |
| 3 | 887134 | WINDSHIELD (#887134) |
| 4 | 269787 | WINDSHIELD WASHER (#269787) |
| 5 | 560173 | Grommet for upper windscreen (#560173) |
| 6 | 886195 | RH Support (#886195) |
| 7 | 886196 | LH Support (#886196) |
| 8 | ||
| 9 | 98257618 | Screw, (#98257618) |
| 10 | 886197 | RH SUPPORT (#886197) |
| 11 | 886198 | LH SUPPORT (#886198) |
| 12 | 977681 | STELVIO WINDSHIELD KNOB (#977681) |
| 13 | 886078 | Threaded pin (#886078) |
| 14 | 886079 | Threaded pin (#886079) |
| 15 | 886236 | THREADED BUSH (#886236) |
| 16 | 887033 | STUD (#887033) |
| 17 | 14615901 | WASHER (#14615901) |
| 18 | 95005310 | WASHER (#95005310) |
| 19 | ||
| 20 | 14217901 | LOCK WASHER (#14217901) USE AP8152105 |
| 21 | 248419 | SPRING PLATE (#248419) |
| 22 | ||
| 23 | ||
| 24 | ||
| 25 | ||
| 26 | 976614 | SCREW (CYLINDER HEAD) (#976614) |
| 27 | ||
| 28 |
