2011 2013 Stelvio 1200 8v Std NTX Timing System
| Position | Part Number | Description |
|---|---|---|
| 1 | 976330 | Distribution Shaft (#976330) |
| 2 | 976381 | Needle Bearing (#976381) |
| 3 | 976488 | ANELLO OR 37,82X1,78 (#976488) |
| 4 | 976331 | Flange (#976331) |
| 5 | 98350315 | Screw (#98350315) |
| 6 | 976355 | DOUBLE SIDE SHIELDED BEARING (#976355) |
| 7 | AP8152166 | Screw (#AP8152166) |
| 8 | 873928 | WASHER (#873928) |
| 9 | 976334 | SPACER (#976334) |
| 10 | 976538 | Drive Wheel (#976538) |
| 11 | 874281 | GEAR FOR TIMING DRIVE CAM SHAFT (#874281) |
| 12 | 14433400 | WASHER (#14433400) |
| 13 | 829232 | Nut for securing front pulley assy. (#829232) |
| 14 | 91600450 | WOODRUFF KEY (#91600450) |
| 15 | 8787074 | Oil pump drive gear (#8787074) |
| 16 | 976665 | DISC SPRING (#976665) |
| 17 | 976649 | NUT FOR CRANKSHAFT (#976649) |
| 18 | 874280 | TIMING PINION (#874280) |
| 19 | 91600365 | Transmission Key 3X6,5 (#91600365) |
