2011 V7 Racer 750 Throttle Body
| Position | Part Number | Description |
|---|---|---|
| 1 | 32112510 | Throttle Body - Breva (#32112510) |
| 2 | 05112830 | Potentiometer (#05112830) |
| 3 | 32115010 | RH Manifold - Breva (#32115010) |
| 4 | 32115710 | Injector Kit Complete (#32115710) |
| 5 | 32530509 | Rod - Breva (#32530509) |
| 6 | AP8152298 | Screw w/ flange (#AP8152298) |
| 7 | 32115510 | Gasket - Breva (#32115510) |
| 8 | 32115011 | LH Manifold - Breva (#32115011) |
| 9 | 98682322 | Screw (#98682322) |
| 10 | 03013800 | WAVE WASHER (#03013800) |
| 11 | 98310609 | Screw (#98310609) |
| 12 | 95100116 | WASHER (#95100116) |
| 13 | 93305057 | CLAMP (#93305057) |
| 14 | 32114310 | Hose - Breva (#32114310) |
| 15 | 93305061 | CLAMP (#93305061) |
| 16 | 32112610 | RH Throttle Body - Breva (#32112610) |
| 17 | 32112611 | Left Throttle Body - Breva (#32112611) |
| 18 | 32718010 | Hose clamp (#32718010) |
| 19 | 97270212 | Shear rivet M5x12 (#97270212) |
| 20 | 973221100027 | KIT DEPOTENZIAMENTO BREVA (#973221100027) |
